FP2, FP2SH Series FP2-PP21 PLC Programmable Logic Controller Panasonic 2-Axis Control

Name: FP2, FP2SH Series FP2-PP21 PLC Programmable Logic Controller Panasonic 2-Axis Control
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: FP2-PP21
Price: 210.00 USD
Availability: InStock

Nombre De La Marca:	Panasonic
Número De Modelo:	FP2-PP21
Cuota De Producción:	1
Precio:	Negociable
Condiciones De Pago:	Los datos de las operaciones de transferencia de dinero a través de los servicios de transferencia d
Capacidad De Suministro:	en stock

Información detallada

Descripción del producto

Información detallada

Lugar de origen:

Japón

Certificación:

Detalles de empaquetado:

Caja nueva y original

Capacidad de la fuente:

en stock

Resaltar:

PLC Programmable Logic Controller

Panasonic Programmable Logic Controller

FP2-PP21 PLC Controller

Descripción del producto

Detailed Product Description

Brand:	Panasonic	Model Number:	FP2-PP21
Country Of Origin:	Japan	Type:	PLC Programmable Logic Controller
Number Of Outputs And Type:	16 - Pulse (4), PWM (4), Solid State (8)	Expandable:	3 Modules Max
Voltage - Supply:	24VDC	Operating Temperature:	0°C ~ 55°C
Highlight:	ethernet plc controllers , industrial automation using plc

FP2, FP2SH Series FP2-PP21 PLC Programmable Logic Controller Panasonic 2-Axis Control

Specifications

Manufacturer:	Panasonic Industrial Automation Sales
Product Category:	Controllers - PLC Modules
For-Use-With-Related-Products:	FP2, FP2SH Series
Series:	FP2
Type:	Motion Control Module
Termination-Style:	Rectangular Connector
Mounting-Type:	Backplane
Features:	2-Axis Control
Voltage-Supply:	-
Number-of-Inputs-and-Type:	-
Number-of-Outputs-and-Type:	2 - Pulse

Panasonic PLC Module FP2-PP21

Extended Product Type : FP2 series
Product ID: FP2-PP21
PAnasonic Type Designation : FP2 series

Features

A high-performance model for high-speed operation
Scanning time of 1ms for 20k steps. With an operating speed at the top of its class, super high-speed processing is made possible. The result is a dramatically decreased tact time and high-speed device.
Large programming capacity of up to 120k stepsLarge programming capacities of 60k and 120k are available, depending on the model.
Combine modules like building blocks
I/O units, intelligent units, power supply units and backplanes can be used together for the FP2 and the FP2SH. I/O units can be located anywhere on the backplane.
Optional small PC card is also available
The small PC card is available for programming backup or data memory expansion. This allows you to process great amounts of data.
Built-in comment and real-time clock functions
These functions, optional with the FP2, are built right into the FP2SH.

Specification

Transistor output, 2 axes

The following are some of the drive models, both new and used are stocked:

MSDA3A3A1A	MSDA5A3A1A	MSDA013A1A
MSDA023A1A	MSDA043A1A	MSDA083A1A
MDDA103A1A	MDDA153A1A	MDDA203A1A
MDDA253A1A	MDDA303A1A	MDDA353A1A
MSDA403A1A	MSDA503A1A	MSD023A1XXV
MSDA083A1XXV	MSD043A1X	MSDA043D1A
MQDA043A1A	MUDS043A1A	MUDS023A1A
MUDS083A1A	MUMS082A1E0S	MUDS083A1M
MUMA012P1T	MUMA022P1T	MUMA042P1T
MUMA042P1S	MUMA012P1S	MUMA022P1S
MUMS082P1S	MSDA043A1XXV	MSDA013A1XXV
MKDET1505P	MLDET2310P	MUMA082P1T
MLDET2510P	MKDET1310P	MUMS042A1AOS
MSM041A211	MQMA042A1E	MSMA022P1A
MSM042P1B	MSM042AJB	MSM011P1N
MQMA022S2P	MSM012AJA	MSM012P1F
MDMA152S1C	MSM042AJA	MQMA012C2P
MSMA022A1B	MSM021DJE	MSD043A1X
MSD043A1XX	MSM042A1A	MSM5AZA1B
MUMS012C2U1S	MUMS012A1F0S	MSMZ082A1B
MSD013A1XX	MSM012A1A	MSMA012C1A
MSDA013D1A	MSMA5AZS1A	MQMA012P1B
MSMD042P1T	MUMS022A1B0S	MFM082A1C
MQMA042A1E	MSMA022C1A	MSMA022C1E
